名称：气动平行三爪-断气保护-常开
Name:Pneumatic parallel three claws
型号(Mode1):FY-JGZ160-2-1S
P:空气压力(bar)P:Air Pressure(bar)
L:到作用点距离(mm)L:Exertion Length(mm)
开闭范围(Stoke):2*8=16mm
产品重量(Weight):8kg
最大附件长度(Max.length attach):180mm
配管连接▣(Fitting size):PF(G)1/8"
理论夹持力-开(Gripping force:Open):8480N
最小弹簧力(Minimum spring force)：2090N
单循环空气消耗量（Air consumption per cycle).:520cm
开闭时间（Closeing./Opening time):0.4/0.8Sec
重复精度(Repeat accuracy):0.02mm
连续使用次数(Continuation usage amount).:40
使用气压(Operating pressure):3-8bar
周围温度(Ambient temperature):-5to90℃(-10to130℃)
润滑(Lubrication):不需要（Needless)
根据IEC60529标准安全防护：IP40
Safety protection according to IEC60529 standard:IP40
所有数据在6Bar时测量(All data were measured at6Bar)
重复精度：连续动作100次以后的检测值
After 100 consecutive strokes to end positions
